Transmitter / Receiver RF Room Thermostat 7 Day Programmable 6 Time / Temp Per Day

Brand Name : OCSTAT

Model Number : ST2402RF

Certification : CE,ROHS

Place of Origin : GuangDong

MOQ : 1pcs

Price : US$23.2-25PCS

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 5000pcs/mouth

Delivery Time : 7-50days

Packaging Details : Standard exporting package

Type : Floor Heating Parts, Floor Heating Systems, Floor Heating Thermostats, Bat-low Indicator, HVAC Systems

Color : white

Floor heating part type : Floor Heating Thermostats, Floor Heating Cables, Floor Heating Panels, under flooring heating system

Application : Underfloor Heating System, Water Heating/Electric Heating System/Boiler, Indoor underfloor heating, electric underfloor heating system.Radiant heating room thermostat, Water Heating System

Dimensions : 120 x 77 x 28 mm (without holder)

Standby current : 30uA, Lighting current ≤ 6mA

Contact Now

Specification

Transmitter / Receiver Wireless 7 Day programmable 6 Time & 6 Temp,per day, with backlight Thermostat ST2402RF

Transmitter (thermostat):

1.Programmability: 7 Day, 5/2 Day and 24 hour Programmable

2.Display Temperature Range:0°C~40°C (in 0.1°C increments)

3.Adjustable Temperature Range:5°C~35°C (in 0.5°C increments)

4.Temperature measurement accuracy: ±1°C (at 20°C)

5.Power Supply: DC 2x AAA 1.5V Alkaline Batteries

6.Switchable Current: 6 A (2 A inductive load), 230V

7.Low Battery Indicator: Display “Transmitter / Receiver RF Room Thermostat 7 Day Programmable 6 Time / Temp Per Day“ when battery is less than 2.7V

5.Load Rating: 6(2)A, 230V

6.Low Battery Indicator: Display “Transmitter / Receiver RF Room Thermostat 7 Day Programmable 6 Time / Temp Per Day“ when battery is less than 2.7V

8.Standby current:30uA, Lighting current ≤ 6mA

9.Backlight colour: White

10. Dimensions: 120 x 77 x 28 mm(without holder)

Receiver:

1. Power Supply: 230VAC, 50HZ

2. Operating Frequency:868.35MHZ

3. Transmission Distance: approx. 100m in open terrain

4. Consumption: 6W

5. Maximum Load: 6(2)A, 230V

6. Dimensions: 86 x 86 x 26 mm

Transmitter / Receiver RF Room Thermostat 7 Day Programmable 6 Time / Temp Per DayTransmitter / Receiver RF Room Thermostat 7 Day Programmable 6 Time / Temp Per DayTransmitter / Receiver RF Room Thermostat 7 Day Programmable 6 Time / Temp Per DayTransmitter / Receiver RF Room Thermostat 7 Day Programmable 6 Time / Temp Per DayTransmitter / Receiver RF Room Thermostat 7 Day Programmable 6 Time / Temp Per Day
